Technical Advantages
Technical Specifications
| Project | Parameter | |
|---|---|---|
| Model | ZS-325, ZS-335, ZS-350, ZS-635, ZS-650 | |
| Lens focal length mm | 25, 35, 50, 35, 50 | |
| Field of view° | 10.6×7.7°, 7.5×5.7°, 5.3×4°, 12.6×10°, 8.8×7° | |
| Target distance (person/meter) | ||
| Discover the distance | 2500m, 3500m, 5000m, 3500m, 5000m | |
| Identification distance | 625m, 875m, 1250m, 875m, 625m | |
| Resolution distance | 313m, 438m, 438m | |
| Response band | 8~14 μm | |
| Sensor Type | Uncooled focal plane detector | |
| NETD | < 35 mk (@25° C, F# = 1.0) | |
| Resolution | 384×288, 640×512 | |
| Frame rate | 50 fps | |
| Pixel size | 12 μm | |
| Display resolution | 1024×768 | |
| Monitor | OLED 0.39 | |
| Brightness | Adjustable | |
| Contrast | Adjustable | |
| DDE enhanced mode | Adjustable | |
| Electronic Amplification | ×1, ×2, ×4, ×8 | |
| False Color Mode | Black hot, white hot, red hot, iron red | |
| Bad pixel repair | support | |
| Image Display | support | |
| Non-uniformity correction | support | |
| Image smoothing function | support | |
| Image detail enhancement | support | |
| Scene Mode | Normal, City, Forest | |
| Shutter control | Manual / Automatic | |
| CVBS | support | |
| Frame rate | 50 Frames | |
| Start-up time | ≤ 10 s | |
| Parameter preservation | support | |
| Crosshair | support | |
| Menu | support | |
| WIFI | support | |
| Hot Spots | support | |
| Photograph | support | |
| Video | support | |
| Removable battery | support | |
| Hot Spot Tracking | support | |
| Automatic shutdown | support | |
| Battery capacity | 3400mAh | |
| Image super-resolution | support | |
| Restore Defaults | support | |
| Equipment time calibration | support | |
| Trajectory calculation | support | |
| Probability Ranging | support | |
| Storage Memory | 32G | |
| Picture-in-Picture | support | |
| Mobile APP | support | |
| Battery life | 5H (individual observation time) | |
| Weight | 720g | |
| Size | 215×75mm |
Application Scenarios and Solutions
Professional Hunting
- At night or in low light conditions, the TI-640 Pro provides a clear thermal imaging field of view that can easily identify targets at long distances, making it an ideal piece of equipment for professional hunting.
- Ultra-long detection distance ensures early detection of prey
- High-resolution imaging helps accurately identify prey species
- Multiple aiming baselines to adapt to different hunting scenarios
Border and Regional Security
- Provides 24/7 surveillance capabilities for border patrol and regional security, and can maintain efficient surveillance even in complete darkness or inclement weather conditions.
- Long-distance personnel detection and identification capabilities
- Built-in GPS records location information
- Video recording feature records suspicious activity
Wildlife Research
- Providing wildlife researchers with a non-intrusive observation tool to observe animal behavior from a distance at night without disturbing the research subjects.
- Highly sensitive detection of small animal heat signatures
- Image/video recording function facilitates research and analysis
- Long battery life to meet long-term field work
