Fusion Telescope Panoramic Display
  • Fusion Telescope Panoramic Display
Fusion Imaging Binoculars

Fusion Imaging Binoculars

The fusion telescope combines multiple imaging technologies to achieve seamless integration of visible light and infrared thermal imaging, providing clear and rich visual information. The device is suitable for security monitoring, field reconnaissance and environmental monitoring, and can accurately identify targets in complex environments. The high-performance optical system is combined with intelligent image processing technology to improve observation effects and target recognition capabilities, meeting the needs of professional users for multi-dimensional information.

Basic Specs

  • High performance detector
    384×288 resolution
    17μm pixel size
  • Optical system
    40mm F1.2 lens
    Binocular 1024×768 OLED

  • Detection performance
    1500m detection distance
    <40mK thermal sensitivity

Custom Options

Technical Advantages

  • Binocular Optical System
    The binocular display design reduces visual fatigue caused by long-term observation and provides a more natural observation experience.


  • High-performance imaging
    384×288 high-resolution detector, 40mK high sensitivity, can provide clear images in complex environments


  • Battery life
    Adopt high-performance lithium battery, single charge can work continuously for 5 hours, support quick battery replacement


  • Protection level
    IP67 waterproof and dustproof design, -30°C to +55°C wide temperature range working capability


  • Image Processing
    Support multiple pseudo color modes, digital detail enhancement, and image optimization algorithms


  • Wireless connectivity
    Support Wi-Fi image transmission, you can remotely view and control the device through the mobile phone App

Technical Specifications


 FFU6213B - Infrared Detector and Lens FFU6213B - Low light (CCD) and Lens



1. Product Overview
Resolution 640×512 800×600
Pixel spacing 17μm 18μm
NETD ≤45mK@25℃ -
Working band 8 - 14μm -
Frame rate 25Hz 25Hz
Focal length 37.8mm 40mm
Focus Manual Manual



2. Image Display
Monitor 0.39″OLED, resolution 1024×768 0.39″OLED, resolution 1024×768
Electronic Amplification ×2 ×2
Image Adjustment

Target identification, brightness, contrast,

Automatic/manual shutter correction, polarity, image magnification

Target identification, brightness, contrast,

Automatic/manual shutter correction, polarity, image magnification



3. Fusion detection and identification distance
Detection distance

Personnel (1.7×0.5m): 1200m

Vehicle (2.3m×2m): 700m

Personnel (1.7×0.5m): 1200m

Vehicle (2.3m×2m): 700m
Identification distance

Personnel (1.7×0.5m): 400m

Vehicle (2.3m×2m): 560m

Personnel (1.7×0.5m): 400m

Vehicle (2.3m×2m): 560m



4. Others
Image storage/ video storage BMP file storage/AVI video file storage BMP file storage/AVI video file storage
Memory Card 32G T card 32G T card
Video Output Q9 Q9
Data interface/serial port USB/RS232 USB/RS232
Tripod Mount Standard, 1/4 inch Standard, 1/4 inch
Field of view/illuminance adjustment range 16°×12°/4 - +4 Gain 16°×12°/4 - +4 Gain
Direction/ Positioning/ Wireless Transmission Electronic compass/ Beidou or GPS/WIFI Electronic compass/ Beidou or GPS/WIFI
Battery 2 18650 rechargeable lithium batteries 2 18650 rechargeable lithium batteries
Start-up time/ continuous working time About 10s / ＞3.5h About 10s / ＞3.5h
Operating temperature -40℃ - +50℃ -40℃ - +50℃
Storage temperature -45℃ - +60℃ -45℃ - +60℃
Protection level IP67 IP67
Weight/Dimensions

＜1300g (including 2 18650 lithium batteries)

/205 (L)×160 (W)×70 (H) mm

＜1300g (including 2 18650 lithium batteries)

/205 (L)×160 (W)×70 (H) mm

Application Scenarios and Solutions

Border Patrol

  • Thermal imaging telescopes can penetrate complex environments all day and night during border patrols, accurately identify targets at long distances, and are portable and easy to operate, providing efficient early warning protection for border control.
  • Affected by the environment such as day and night, haze, dust, etc., it can penetrate camouflage to capture the heat source of human body or vehicle, and maintain stable detection capability under complex weather conditions
  • Equipped with a high-magnification optical system and a high-sensitivity thermal detector, it can clearly distinguish the target's outline and movement trajectory from several kilometers away, and provide early warning of illegal crossing behavior.
  • The lightweight design is suitable for patrols on foot or in vehicles, has a long battery life, and can be quickly put into use without complex debugging, making it suitable for border guards to guard for a long time.

Large Security

  • Thermal imaging telescopes assist large-scale security, can quickly locate hidden targets, achieve large-scale real-time monitoring, and operate with low interference, providing efficient support for security assurance
  • It can penetrate crowds and obstacles to capture abnormal heat sources, quickly identify hidden suspicious persons or prohibited equipment, and is not affected by light.
  • With a telephoto lens, it can achieve long-distance coverage and simultaneously monitor large venues, event sites and other wide-area scenes to improve security efficiency
  • Non-visible light detection avoids strong light exposure, suitable for secret control at night or in sensitive areas without affecting normal activities

Outdoor Adventure

  • Thermal imaging telescopes help outdoor explorers identify the environment and targets in the dark and in bad weather. They are portable and low-power, improving the safety of exploration and the ability to judge the path.
  • Nighttime environmental perception: No need to rely on light, it can clearly present terrain, animal and plant heat sources in the dark, and avoid wild animals or dangerous terrain
  • Bad weather penetration: penetrate fog, haze, light smoke, etc., maintain the identification of the path and target, and avoid getting lost or missing key locations
  • Low power consumption and portable battery life: Lightweight design is suitable for outdoor loads, long battery life is enough for multi-day adventures, simple operation without complicated debugging
