Technical Advantages
Technical Specifications
| Function parameters | M3-C |
|---|---|
| Series Model | M3-C |
| Sensor Type | (Uncooled focal plane detector) Vanadium oxide |
| Spectral response | 8-14um |
| Pixel | 12um |
| Array size | 384×288 (effective image array) |
| NETD | ≤35mk( f/1.0 50Hz 300K) |
| Frame rate | 60Hz |
| Analog image interface | CVBS (PAL) |
| Control interface | UART |
| Button functions | Electronic zoom, pseudo color switching |
| False color mode | White Hot (default mode), Black Hot, Red Hot, Iron Red, Fusion, Green Light |
| Scene Mode | User, Plain, Forest |
| brightness | Support adjustable |
| Contrast | Support adjustable |
| Electronic zoom | 1-X-8X continuous zoom (step size 0.5) |
| Shutter mode | Gear, automatic gear |
| Helmet calibration | UART serial port host computer helmet calibration |
| Non-uniformity correction (NUC) | UART serial port host computer calibration |
| Power input | 4.5v-18v |
| Operating temperature | -30℃~+60℃ |
| Power consumption | ≤0.8 |
| Impact | 1000g |
| Lens specifications | 4mm, 9.1mm |
| Field of view | Horizontal 54.2°, vertical 42°, diagonal 65.3°; horizontal 28.4°, vertical 21.5°, diagonal 35.1° |
| Secondary development | / |
| size | 17.3mm×17.3mm×35.7mm |
| weight | 16g |
Application Scenarios and Solutions
Field security monitoring
- It is suitable for security in wild areas such as forests and plains, and can capture abnormal heat sources with high sensitivity detection.
- Supports forest and plain scene modes, suitable for outdoor environments
- 1000g impact resistance, adaptable to complex terrain in the wild
- Wide operating temperature range (-30°C ~ +60°C) to cope with extreme climates
Portable device integration
- It can be embedded in small security equipment, and its lightweight design meets the needs of mobile monitoring.
- Only 16g weight and small size, easy to integrate into devices
- 4.5-18V wide voltage power supply, suitable for a variety of devices
- Electronic zoom function, flexible adjustment of observation range
Industrial temperature detection
- Used for thermal monitoring of industrial equipment and rapid identification of abnormal temperature points.
- 8-14um spectral response, accurately capturing device thermal radiation
- Multiple pseudo-color modes to intuitively present temperature differences
- 60Hz high frame rate, real-time feedback of temperature changes
