Technical Advantages
Technical Specifications
| Specifications | TB335 | TB350 | TB635 | TB650 | |
| Lens specifications | Focal length (mm) | 35mm | 50mm | 35mm | 50mm |
| Field of view (FOV) | 7.5°*5.7° | 5.3°*4° | 5.3°*4° | 8.8°*7° | |
| Detection distance | 3500m | 5000m | 3500m | 5000m | |
| Identification distance | 875m | 1250m | 875m | 1250m | |
| Identification distance | 438m | 625m | 438m | 625m | |
| Detector specifications | Detector resolution | 384*288 | 640*512 | ||
| Display resolution | OLED3.9 1024*768 | ||||
| Noise Equivalent Temperature Difference (NETD) | <35mK(@25°C,F/#=1.0) | ||||
| Detector type | Uncooled focal plane array detector (VOx - Vanadium Oxide) | ||||
| Spectral response | 8 - 14um | ||||
| Pixel pitch | 12um | ||||
| Frame rate | 50Hz | ||||
| Device Function | Key operation | 2 buttons + 1 dial switch | |||
| False color mode | White hot (default), black hot, red hot, iron red, etc. | ||||
| Scene Mode | User, Plain, Forest | ||||
| Digital zoom | 1x-8x zoom | ||||
| Shutter Mode | With shutter, automatic shutter mode | ||||
| Function Menu | NUC, crosshair, WIFI hotspot, photo and video recording, laser rangefinder, removable battery, restore default settings, version information, DDE, gyroscope, blind pixel calibration, ballistic calculation, accelerometer, picture-in-picture, mobile application, bad pixel correction, brightness, contrast, digital zoom, shutter mode, clip mode | ||||
| Physical properties | Battery capacity | Single battery 1850G/2400mAh | |||
| Storage Memory | 32G | ||||
| Working hours | 3 hours (individual observation time) | ||||
| Protection level | IP66 | ||||
| Power consumption | ≤2w | ||||
| impact resistance | 1000g | ||||
| Weight (including battery) | 550g | 578g | 550g | 578g | |
| Dimensions (excluding rubber sleeve) | 134x 80x 62mm | 136x 80x 62mm | 134x 80x 62mm | 136x 80x 62mm | |
| Shell material | Metal | ||||
| Work Environment | -20°C - +60°C | ||||
Application Scenarios and Solutions
Border Patrol Monitoring
- Detect border movements from a long distance, adapt to complex terrain and severe weather, and ensure border security.
- 3500 detection distance can cover a wide border area
- -20℃~+60℃ operating temperature adapts to border environments with large temperature differences between day and night
- Multiple pseudo-color modes help quickly identify suspicious targets
Wildlife tracking
- Observe wild animals non-contactly, accurately capture their movements at night, and assist in ecological research.
- 12μm pixel pitch and highly sensitive detectors clearly visualize animal heat sources
- Lightweight design (550-578g) makes it easy to carry outdoors
- Shock-resistant to 1000g, suitable for bumps in complex terrain
Maritime search and rescue operations
- Search for targets at sea at night or in bad weather to improve search and rescue efficiency and success rate.
- IP66 protection level can withstand sea moisture and wind and waves
- The maximum identification distance of 1250m can quickly locate people or ships that fall into the water
- Support video recording function, which can retain the search and rescue process for subsequent analysis
